Sandvik Turning Insert TNMG160412-SM S205

• First choice for processing S-type materials
• Continuous and interrupted cuts for a wider range of applications
Size:
Material:
Color:
Availability:
Quantity:
  • TNMG160412-SM S205

  • Sandvik

Product data
Material classification level 1(TMC1ISO)
S
Operation type(CTPT)
Medium
Insert mounting style code(IFS)
2
Fixing hole diameter(D1)
3.81 mm
Insert size and shape(CUTINTSIZESHAPE)
TN1604
Cutting edge count(CEDC)
6
Inscribed circle diameter(IC)
9.525 mm
Insert shape code(SC)
T
Cutting edge effective length(LE)
4.8 mm
Corner radius(RE)
1.191 mm
Wiper edge property(WEP)
false
Hand(HAND)

N
